Permanent Magnet DC Servo Motor
Project Model	Supply Voltage VDC	Rated Speed r/min	Rated Power W (Reference Value)	Rated Torque N·m	Rated Current A	Resistance Ω	Inductance mH	Weight Kg	Basic Dimensions (Outer Diameter × Inner Diameter × Axial Length) mm
J30SYX02-Z	33	7200	9.05	≥0.012	≤0.8	7	≤2	≤0.4	Φ31*86.6
J36SYX02-Z	24	2500	10.5	≥0.04	≤1	7.8		0.365	Φ36*57.5
J40SYX05-Z	28.5	9100	85.8	0.09	≤4.6			1.05	Φ42*135
J50SYX03A-Z	40	14000～15000	124.6	0.085	≤5			0.65	Φ50*71
J55SYX05	27	6000	35	0.25	≤2.2	≤1.5		1	Φ55*88.5
J59SYX04-ZY	28	≥300	125	0.9	≤4			1.5	595953
J60SYX03-Z	24	2200	230.4	1	≤19		≤10	1.3	Φ60*86.5
J63SYX02	27	2500	39	0.149	≤2.5			1.03	Φ63*100.5
J64SYX06-Z	48	2500	214	0.82	≤6.5	≤0.9		3	Φ64*120
J70SYX02-Z	28	800	25.1	0.3	≤1.5	≥2.4	≤15	1.3	Φ70*75
J75SYX05-Z	28	3000	257	0.82	≤40	≤0.15		2.6	Φ75*132
J80SYX03-Z	24	3900	653.4	1.6	≤45	≥0.08	≤0.4	2	Φ80*76
J88SY03-Z	48	4500	386	0.82	≤11	≤1		4	Φ88*127
J100SYX05	26	1000	250	2.3	≤16	≤0.3		11	Φ100*156
110SYX60	180	10000	600	0.5	≤4.8	≤0.9		6	Φ110*112.5
J110SYX271	28	5000	200	0.2	≤15.5	≤0.1		6	Φ110*150
J120SYX-Z50G	110	2500	370	1.44	≤4.5	0.8	4	12	Φ120*280
J122SYX07-Z	22	5600	4397	7.5	≤295	0.01		12	Φ122*198
J125SYX04-Z	60	4300	2250	5	55			7.5	Φ125*167
J130SYX05	60	1700	600	3.3	≤16.5	≤0.4		18	Φ130*197
132SYX-01A	270	2000	1500	7.2	6.6			13	Φ132*200
J150SYX01-Z	24	≥60	16.3	≥2.6	≤3.5	≤7	≤40	6	Φ150*40
J200SYX12	72	600	2000	32	≤38	≤0.5		12	Φ200*115
